Coolant Temp Sensor 22630-44B20 Suits Nissan Navara D22 3.0L Zd30Ddt 2001-2006
$36.28
BRAND NEW *OEM QUALITY* ENGINE COOLANT TEMPERATURE SENSOR TO SUIT FORD
PLEASE COMPARE YOUR ORIGINAL SENSOR WITH THE IMAGES WE PROVIDED IN THE LISTING AND CHECK THE DETAILED VEHICLE LIST IN THE SUITABILITY SECTION.
FORD AND MAZDA 2.2L P4AT / 3.2L P5AT TURBO DIESEL ENGINES
[2015-ON] FORD EVEREST UA
[2011-2018] FORD RANGER PX
[2011-2020] MAZDA BT-50 UP UR
1* Temperature Sensor (2 PIN PLUG) -Clip-In Sensor – Suits ECU. The engine coolant temperature sensor (CTS) is used to measure the temperature of the engine coolant of an engine. The readings from this sensor are then fed back to the engine control unit (ECU), which uses this data to adjust the fuel injection and ignition timing. Common signs of a bad or failing coolant temperature sensor include poor fuel economy, engine overheating black smoke from the engine, and the Check Engine Light turning on.
[01/15 – 12/18] FORD EVEREST UA 3.2L 5cyl Duratorq TDCi P5AT 143kW
[01/16 – 12/18] FORD EVEREST UA 3.2L 5cyl Duratorq TDCi P5AT 143kW
[01/18 ON] FORD EVEREST UA II 3.2L 5cyl Duratorq TDCi P5AT 143kW
[09/11 – 05/15] FORD RANGER PX (11-15) 2.2L 4cyl Duratorq TDCi P4AT 110kW
[09/11 – 05/15] FORD RANGER PX (11-15) 3.2L 5cyl Duratorq TDCi P5AT 147kW
[06/15 – 06/18] FORD RANGER PX II (15-18) 2.2L 4cyl Duratorq TDCi P4AT 118kW
[06/15 – 12/17] FORD RANGER PX II (15-18) 2.2L 4cyl Duratorq TDCi P4AT 118kW
[06/15 – 06/18] FORD RANGER PX II (15-18) 3.2L 5cyl Duratorq TDCi P5AT 147kW
[09/11 – 08/15] MAZDA BT-50 UP (11-15) B22P 2.2L 4cyl P4AT MZ-CD 110kW
[09/11 – 08/15] MAZDA BT-50 UP (11-15) B32P 3.2L 5cyl P5AT MZ-CD 147kW
[09/15 – 06/20] MAZDA BT-50 UR (15-20) B22P 2.2L 4cyl P4AT MZ-CD 110kW
[09/15 – 06/20] MAZDA BT-50 UR (15-20) B32P 3.2L 5cyl P5AT MZ-CD 147kW
[01/13 – 12/16] FORD TRANSIT CUSTOM VN 2.2L 4cyl Duratorq CYF4 CYFF 92kW
[01/11 – 12/13] FORD TRANSIT VM 2.2L 4cyl Duratorq CVR 114kW
[01/10 – 12/11] FORD TRANSIT VM 2.2L 4cyl Duratorq SRF 85kW
[01/15 – 12/18] FORD TRANSIT VO 2.2L 4cyl Duratorq CVR5 UYR6 114kW
[01/14 – 12/18] FORD TRANSIT VO 2.2L 4cyl Duratorq CVR5 UYR6 114kW
What does a Coolant Temperature Sensor do?
The Coolant Temperature sensor changes resistance with the temperature. The Coolant Temperature sensor is critical to many PCM functions such as fuel injection, ignition timing, variable valve timing, and transmission shifting.
Where are these sensors located?
The Coolant Temperature sensor is located in a coolant passage in the engine usually near the thermostat.
Will a malfunctioning Coolant Temp Sensor illuminate the check engine light or affect vehicle operation?
Yes, a failing sensor can illuminate the MIL, and cause the engine to run rich or lean. The transmission may shift incorrectly or not lock up the torque converter.
What are the common causes of failure?
Typically these sensors fail due to corrosion within the coolant system. They may also leak coolant through the wiring connector.
How to determine if these sensors are malfunctioning?
A DTC will be set if an abnormal reading occurs, P0116 for sensor performance, P0117 for low input, or P0118 for high input. The coolant temperature sensor reading should closely match the air charge/manifold temperature reading on a scan tool if the engine has not been run for over an hour. The sensor circuit can be checked for proper voltage using a voltmeter.
Why Buy from Us / What makes Our Coolant Temp Sensors the best?
As an OEM manufacturer, Standard/ Our Supplier has complete control of the manufacturing process from componentry to finished product
Temperature sensor design specifies tight tolerance thermistor response values to assure the accuracy of the temperature measurement and proper part operation
All Coolant Temperature sensors are 100% factory tested to ensure trouble-free performance.
SKU | CCS44 |
Brand: | Aftermarket OEM Replacement |
Part Number: | XS6F12A648CA |
Reference OEM Number: | XS6F12A648CA |
Other OEM Numbers: | 1L2A-12A648-AA, 7C11-12A648-AB, XS6F-12A648-CA |
Related Part Numbers: | CCS44, TCS112, TS10329, TX104 |
Unit Of Measure | ea |
